2L LDPE HDPE PP Blow Molding Machine

2L LDPE HDPE PP Blow Molding Machine

Product Details:

Place of Origin: Cangzhou, Hebei
Brand Name: SANQING
Certification: CE
Model Number: SQ-11

Payment & Shipping Terms:

Minimum Order Quantity: 1 SET
Packaging Details: Wooden Case Package
Delivery Time: 45 Days
Payment Terms: L/C, T/T
Supply Ability: 50 Sets Per Month
Get Best Price Contact Now

Detail Information

Name: Plastic Bottle Blowing Machine For 3L Bottles Material: HDPE/PP/LDPE
Screw Diameter: 65/75mm Product Volume: 200ML- 3 Liter
Machine Weight: 3 Ton Dimension: 4x2.2x2m
Motor Power: 11.5/18.5 KW Production Capacity: 300-400 PCS/HR
Air Consumption: 0.6m3/min 8KG Chiller: Air Cooling
Water Consumption: Water Can Be Recycled Electricity: 380V 3 Phases 4 Wires
Heating Power: 13KW Loader: Auto Loader 300G
High Light:

2000ml Jar blow molding machine


pp blow molding machine 2x2m


hdpe moulding machine 3t

Product Description

Plastic Bottle Blowing machine for 3L Bottles


          This type HDPE plastic bucket/container blow molding machine is suitable to produce 3 liter and small bottles under 3 liter, such as milk bottles, barrels, jars, water bottles, etc.


          The small bottle machine could produce hollow products with material HDPE/LDPE/PP. The machine could operate easily with PLC control system, once operator setup the parameters, the machine could work smoothly without people attention.


         The machine equipped with automatic cutting devices, the waste material could be cutted directly. The die heads could be 1,2,3, 4, so that the production capacity could be fourth times higher.


         The machine is double stations, die heads could be 1-4, so the molds should be reflected accordingly. The production capacity could be faster than only single die head. This machine also could install parison controller system, customer could control the wall thickness easily by parison controller.  For small bottles, the die head could be three or four, customer could choose the quantity based on their needs.


         This machine require 0.6m3/min 8KG air compressor, customer have to prepare the air compressor for machine operation. Chiller, crusher, auto loader is also needed for this kind of machine. Chiller help to cool the molds; crusher will break the waste material to be pieces and re-use again. Auto loader will help customer pump material to the hopper of the extruder.


         If buyer would like to recycle the extra material from plastic bottles, please purchase a crusher to process this job. The Crusher will break plastic to be pieces and operator could mix the recycled material with virgin material and use it again. Usually, mix 10-20% of the recycled material with virgin material, so that the quality could be maintain.


         Auto Loader could be used for the machine, so the user will not need to climb up the machine and put material.



Name             Item
Max. Bottle Volume  3L
Max. Product Dia. 15CM
Production Capacity 400 PC/HR
Allowable Mold Width 230mm
Allowable Mold Thickness 110-230mm
Air Consumption 0.6m3/min
Weight 3 Ton
Dimension 4x2.2x2m
Raw Material HDPE/LDPE/PP





2L LDPE HDPE PP Blow Molding Machine 02L LDPE HDPE PP Blow Molding Machine 1
