Sanqing HDPE Blow Moulding Machine

1 set
Sanqing HDPE Blow Moulding Machine
Features Gallery Product Description Request A Quote
Place Of Origin: Hebei, China
Brand Name: Sanqing
Name: LDPE Ice Lolly Tube Blowing Machine, Blow Molding Machine
Application: Bottle
Plastic Processed: PP, HDPE, PE
Dimension: 3400*1600*1800mm
High Light:

Sanqing hdpe blow moulding machine


120*120*300mm mold hdpe moulding machine


1000ml hdpe moulding machine

Basic Infomation
Certification: CE ISO9001
Model Number: SQ-6
Payment & Shipping Terms
Packaging Details: Angle frame with outside wooden case
Delivery Time: 45 days
Payment Terms: L/C, T/T
Supply Ability: 30 sets/month
Product Description

Product Name

LDPE Ice Lolly Tube Blowing Machine, Blow Molding Machine



  • this machine adopts screw extrusion blow molding process it is controlled by PLC (computer), high precision. It is specially designed for LDPE Ice lolly tube,fruit shape bottle,dropper pipette bottle,toy shape or soft bottle,HDPE milk bottle,yoghurt bottle etc. The machine has awarded CE Certification.

    Easy to operate, high speed to improve production efficiency and lower the production cost, reduce the labor, less Maintain, easy to clean, lower Noisy,Longer Life

    it also suitable to make the HDPE/PP cutting mouth bottle,max.volume is 1000ml

    it also can be 1-6 cavity in one mold depending on the sample

    this machine is first developed by sanqing, also is patented machine, save energy


Main Technical Parameters:

Model 4 station combine model 45/55 6 station combine model 55/65 8 station combine model 65/75
Max bottle volume 1000 1000 1000
Max bottle diameter 7 8 9
Mould size mm 120*120*300 120*120*300 120*120*300
Screw diameter 45/55 55/65 65/75
Screw L/D ratio 25:1
Motor power 5.5/7.5 7.5/11 11/15
Heating power 3 5 8
Air consumption 0.4
Plasticizing capacity 25/40 40/55 55/75
Weight 1500 2000 2500
Size mm 3400*1600*1740 3600*1700*1800 3800*1800*1900
Applicable raw material PE/PP/PVC
Speed regulation method Frequency control of motor speed
Theoretical output 1000-6000
